Nyob rau niaj hnub no txoj kev loj hlob sai ntawm cov kab mob khaub thuas logistics thiab zaub mov kev lag luam, kev ua tau zoo thiab kev ruaj ntseg ntawm kev ua haujlwm hauv chav txias tau dhau los ua qhov tseem ceeb hauv kev lag luam. Hais txog ob qhov kev xav tau ntawm qhov nruab nrab thiab qhov loj me me txias cia chav tsev rau ob qho tib si tshav kub dissipation efficiency thiab qhov chaw siv, condensing units, nrog lawv cov qauv tsim tshwj xeeb thiab superior tshav kub pauv peev xwm, tau dhau los ua kev lag luam nyiam tshiab.
Parameter
| V-hom Ib Leeg Scroll Nruab Nrab Thiab Cov Cua Kub Kub Tsawg -Coled Unit | ||||||||
| Condensing unit qauv | DMD-V-15U | DMD-V-18U | DMD-V-20U | DMD-V-25U | DMD-V-30U | DMD-V-40U | ||
| Cua txias condenser qauv | FNVB 200 | FNVB 240 | FNVB 260 | FNVB300 | NWS 360 | FNVB450 | ||
| Compressor qauv | ZFI59KQE | ZFI68KQE | ZFI81KQE | ZFI96KQE | ZFI 122 KQE | ZFI 140 KQE | ||
| Lub peev xwm txias thiab lub zog | Evaporation | Lub peev xwm txias (KW) | 28.8 | / | / | 50.7 | 63.8 | 70.6 |
| Kub - 10 degree | Lub zog (KW) | 11.1 | / | / | 19 | 23.2 | 25.3 | |
| Evaporation | Lub peev xwm txias (KW) | 17.65 | 20.1 | 23.5 | 30.2 | 38 | 41.8 | |
| Kub-25 degree | Lub zog (KW) | 9.68 | 11.25 | 13.7 | 16.9 | 20.6 | 22.5 | |
| Evaporation | Lub peev xwm txias (KW) | 10.2 | 11.55 | 13.55 | 16.55 | 20.8 | 23 | |
| Kub-40 degree | Lub zog (KW) | 8.12 | 9.43 | 11.5 | 14.8 | 18.05 | 19.7 | |
| Interface loj | Suction yeeb nkab Interface (mm) | 35 | 35 | 35 | 42 | 42 | 42 | |
| Exhaust Pipe Interface (mm) | 22 | 22 | 22 | 35 | 35 | 35 | ||
| Suction yeeb nkab Interface (mm) | 16 | 16 | 16 | 22 | 22 | 22 | ||
| Exhaust Pipe Interface (mm) | 22 | 22 | 22 | 28 | 28 | 28 | ||
| Sab nraud qhov ntev | Ntev L (mm) | 2060 | 2160 | 2320 | 2630 | 2830 | 3110 | |
| Dav W (mm) | 870 | 900 | 900 | 1000 | 1000 | 1000 | ||
| Qhov siab H (mm) | 1750 | 1850 | 1850 | 1900 | 2060 | 2180 | ||
Nco tseg: Condensation kub +45 degree
1. evaporative kub -10℃~ -40 degree
2. Refrigerant R404A / R507A
3.Power Supply 360 ~ 400V / 50Hz 400 ~ 460V / 60Hz
4.Numberof Compressors 1Pcs
Customized Services
| Daim ntawv thov piv txwv | Chav ntsuas kub |
| Txiv hmab txiv ntoo & Zaub qhov kub thiab txias | 10 mus rau 20 degree |
| Txiv Hmab Txiv Ntoo & Zaub Freshness | 0 txog 15 degree |
| Frozen nqaij cia | -5 rau -18 degree |
| ceev khov nqaij cia | -30 rau -35 degree |
| Tuna ntses | -60 degree |
| Kev thauj mus los txias | -80 degree |
Lub npe Convention
DM(1)D(2)-V(3)-20.2(4)U(5)
(1) DM: IB
(2) D: Tsawg kub
G: Kub kub
(3) H: H hom
V: V Type
U: U Type
L: L Hom
(4) 20.2HP: Hwj chim
(5) S: Sab Tawm
U: Tshaj Tawm
Ntim
